Max Weight 20 kg

Use the Request a Quote button on this page or message us on WhatsApp to check pricing and availability for the VPM-2G.

Overview

The VSYS VPM-2G is a universal projector mount built to carry projectors up to 20 kg on either a solid wall or a ceiling, giving installers a single mount that adapts to whichever surface a room offers. An adjustable extension arm reaches from 350mm to 560mm on a wall or 430mm to 650mm from a ceiling, letting installers position the projector at the right distance from the screen.

Four adjustable support arms fan out to fit a wide range of projector hole patterns, and a free-tilting design of +15 to -15 degrees plus swivel of +8 to -8 degrees makes it easy to angle the image forward or backward for better viewing and reduced glare. A quick-release connector lets the projector be installed once and then detached for maintenance without having to re-align it afterward.

Key Features

Wall or ceiling installation: the same mount adapts to either a solid wall or a ceiling, depending on the room.
20 kg load rating: solid steel bracket with a powder-coated finish, available in matte black, gloss grey, or matte white.
Adjustable extension arm: reaches 350mm to 560mm on a wall, or 430mm to 650mm from a ceiling.
Four adjustable support arms: fan out to fit a wide range of projector mounting hole patterns.
Free-tilting design, +15 to -15 degrees: angles the image forward or backward for better viewing and reduced glare.
Swivel, +8 to -8 degrees: fine-tunes horizontal alignment with the screen.
Quick-release connector: installs once, then detaches for maintenance without needing to re-align the projector afterward.
Built-in cable management: keeps power and signal cables concealed along the mount.

Applications

The VPM-2G is built for compact and short-throw projector installations across the UAE and GCC where flexibility on mounting surface matters: classrooms, meeting rooms, training centers, and retail or hospitality spaces where a ceiling point isn't always available. Its short-throw compatible reach and dual wall-or-ceiling design make it a practical choice for smaller rooms and short-throw projector setups.

Because it installs on either a wall or a ceiling and fits a wide range of projector hole patterns, a single mount model can standardize projector installations across a mixed-room rollout, simplifying specification for integrators.

Installation & Setup

Secure the base bracket to a structurally sound wall stud or ceiling joist. Extend the arm to the required reach, adjust the four support arms to match the projector's hole pattern, and connect it via the quick-release connector. Set the tilt and swivel to aim the image at the screen, then route cables through the built-in cable management for a clean finish.

If you'd rather not handle the installation yourself, mounts.ae also offers professional installation across the UAE. Simply select the installation option when you submit the quote form.

Why Buy the VPM-2G from Mounts.ae?

Genuine VSYS build quality, backed by our own warranty support
Fast delivery across Dubai, Abu Dhabi, and the wider UAE/GCC
Optional professional installation available UAE-wide, request it on the same quote form
Dedicated guidance for AV integrators, system integrators, and facilities teams sourcing at scale
Flexible quotes for bulk, corporate, and project-based orders

For project quantities or full technical documentation, use the Request a Quote button on this page or message us on WhatsApp.

View full details

Technical specifications

Load capacity	20 kg (44 lbs)
Mount movement	Tilt +15 to -15 degrees, swivel +8 to -8 degrees, extension arm 350mm-560mm (wall) or 430mm-650mm (ceiling), mounting spread 225mm-316mm
Material	Solid steel, powder coating, matte black, gloss grey, or matte white

Product details

Use the Request a Quote button on this page or message us on WhatsApp for more on the VPM-2G.

Package Contents

Each VPM-2G ships with the base bracket, the adjustable extension arm, four support arms, a full mounting hardware kit, and printed installation instructions.

Warranty

Every VSYS product from Mounts.ae is backed by a 1-year replacement warranty covering manufacturing defects and product malfunctions. This warranty does not cover damage or performance issues arising from normal usage, misuse, or improper installation. If a genuine manufacturing defect is confirmed within the warranty period, we will replace the product.

Sustainability

The VPM-2G is built from solid steel with a durable powder-coated finish designed to resist corrosion and wear over years of use, reducing the need for replacement.

Expandability

The VPM-2G's dual wall-or-ceiling design and adjustable extension arm mean it can accommodate a range of room layouts and projector positions within its rated class, giving you flexibility if the installation changes later.

Distribution

Mounts.ae holds VSYS stock in the UAE for fast dispatch, with delivery available across Dubai, Abu Dhabi, and the wider GCC.

For more information on the VPM-2G, use the Request a Quote button on this page or message us on WhatsApp.

Frequently asked questions

What size and type of projectors does this mount support?

The VPM-2G is a universal projector mount rated for projectors up to 20 kg (44 lbs). Four adjustable support arms fan out to fit a wide range of projector mounting hole patterns, covering most compact and short-throw projectors.

What is the maximum weight it can hold?

It carries projectors up to 20 kg (44 lbs). The bracket is built from solid steel with a powder-coated finish, available in matte black, gloss grey, or matte white.

Can this mount be installed on either a wall or a ceiling?

Yes. The VPM-2G is designed for both solid-wall and ceiling installation, so the same mount can adapt to whichever surface a room offers rather than needing a separate model for each.

How far does the mount extend from the wall or ceiling?

The extension arm reaches from 350mm to 560mm when installed on a wall, or 430mm to 650mm when installed on a ceiling, letting you position the projector at the right distance from the screen.

How much can the projector be tilted or swiveled?

It has a free-tilting design of +15 to -15 degrees and swivels from +8 to -8 degrees, making it easy to angle the image forward or backward for better viewing and reduced glare.

Can the projector be removed for maintenance without losing the alignment?

Yes. A quick-release connector lets the projector be installed once and then detached for servicing or replacement without having to re-align the mount afterward.

Does mounts.ae offer installation services?

Yes. Mounts.ae offers professional installation across the UAE as an add-on to your order. Simply select the installation option when you submit the Request a Quote form, or mention it when you message us on WhatsApp, and we'll include it in your quote alongside the mount itself. See our installation services page for full details on residential and bulk installs.

How do I order this for a bulk or project installation?

Use the Request a Quote button on this page, or message us on WhatsApp with your quantity and project details. We supply system integrators and businesses on a project basis across the UAE and GCC, and we'll follow up with next steps for your requirement.

Where can I buy VSYS projector mounts?

VSYS projector mounts are available through mounts.ae, based in the UAE and serving system integrators and businesses across the UAE and GCC. Use the Request a Quote button on this page, or message mounts.ae directly on WhatsApp, to get started with your order or enquiry.
