Adjustable Double-Pole Ceiling TV Mount for 37"-80" TVs, Up to 70 kg (VCM-CE1046D-02) | VSYS

Screen Size 37" - 80"
Max VESA 600x400mm
Max Weight 70 kg

Use the Request a Quote button on this page or message us on WhatsApp to check pricing and availability for the VCM-CE1046D-02.

Overview

The VSYS VCM-CE1046D-02 is a double-pole ceiling TV mount built for displays from 37" up to 80", combining a wider height adjustment range with strong load support. Its twin-pole design extends from 695mm to 1565mm below the ceiling, giving installers a wide window to match a range of real ceiling heights from a single mount.

The display attaches to a detachable VESA plate that swivels and tilts from +3 to -20 degrees for the best viewing position, and internal cable management keeps wiring hidden inside the poles for a clean, professional finish. It carries screens up to 70 kg, making it a dependable choice for permanent commercial ceiling installations.

Key Features

Heavy-duty 70 kg load rating: a double-pole design spreads the load for confident support of large commercial displays.
Wide telescoping range, 695 to 1565mm: covers a broad range of ceiling heights from a single mount.
Tilt +3 to -20 degrees: angles the display for the best viewing position beneath the ceiling.
Detachable VESA plate: simplifies installation, letting the plate be fitted to the display before it's lifted into place.
Internal cable management: routes cabling inside the poles for a clean, concealed finish.
VESA compatible up to 600x400mm: covers most displays in this size class.

Applications

The VCM-CE1046D-02 is built for commercial spaces across the UAE and GCC where a ceiling mount is the practical choice: retail floors, restaurants and QSR dining areas, waiting rooms, and conference rooms with a central table layout. Its wide height adjustment range also suits spaces with varying ceiling heights across a multi-location rollout.

Because it spans a 37"-80" range and a wide height window, a single mount model can cover a broad mix of screen sizes and ceiling heights across a project, simplifying specification for integrators.

Installation & Setup

Secure the ceiling plate to a structurally sound ceiling joist or slab. Extend the double poles to the required height and lock them in place, then attach the display to the detachable VESA plate before lifting it into position. Route cables through the poles for a clean finish, and set the tilt angle to suit the viewing position. Given the weight and ceiling-mounted nature of this installation, a two-person team and a structural safety check are recommended.

If you'd rather not handle the installation yourself, mounts.ae also offers professional installation across the UAE. Simply select the installation option when you submit the quote form.

Why Buy the VCM-CE1046D-02 from Mounts.ae?

Genuine VSYS build quality, backed by our own warranty support
Fast delivery across Dubai, Abu Dhabi, and the wider UAE/GCC
Optional professional installation available UAE-wide, request it on the same quote form
Dedicated guidance for AV integrators, system integrators, and facilities teams sourcing at scale
Flexible quotes for bulk, corporate, and project-based orders

For project quantities or full technical documentation, use the Request a Quote button on this page or message us on WhatsApp.

View full details

Technical specifications

Load capacity	70 kg (154 lbs)
VESA compatibility	Up to 600x400mm
Screen size range	37" - 80"
Mount movement	Tilt +3 to -20 degrees, swivel
Material	Double-pole steel construction, powder-coated black
Wall clearance	Telescoping poles 695-1565mm (27.4"-61.6")
Certifications	Strength tested

Product details

Use the Request a Quote button on this page or message us on WhatsApp for more on the VCM-CE1046D-02.

Package Contents

Each VCM-CE1046D-02 ships with the ceiling plate, the double telescoping poles, the detachable VESA plate, a full mounting hardware kit, and printed installation instructions.

Warranty

Every VSYS product from Mounts.ae is backed by a 1-year replacement warranty covering manufacturing defects and product malfunctions. This warranty does not cover damage or performance issues arising from normal usage, misuse, or improper installation. If a genuine manufacturing defect is confirmed within the warranty period, we will replace the product.

Sustainability

The VCM-CE1046D-02 is built from steel with a durable powder-coated finish designed to resist corrosion and wear over years of use, reducing the need for replacement.

Expandability

The VCM-CE1046D-02's VESA compatibility up to 600x400mm and wide telescoping range mean it can accommodate a range of display sizes and ceiling heights within its rated class, giving you flexibility if you upgrade to a different screen later.

Distribution

Mounts.ae holds VSYS stock in the UAE for fast dispatch, with delivery available across Dubai, Abu Dhabi, and the wider GCC.

For more information on the VCM-CE1046D-02, use the Request a Quote button on this page or message us on WhatsApp.

Frequently asked questions

What size TVs and displays does this ceiling mount support?

The VCM-CE1046D-02 is designed for flat displays from 37 up to 80 inches. As long as your screen falls within that size range and its weight and VESA pattern match the mount's specifications, it will mount securely, covering most large commercial displays in this class.

What is the maximum weight it can hold?

It carries displays up to 70 kg (154 lbs). Its double-pole design spreads the load for a dependable safety margin on large, permanently installed commercial panels hanging from the ceiling.

What VESA patterns is it compatible with?

It supports VESA mounting patterns up to 600x400mm. Check the pattern on the back of your screen or in its manual to confirm the fit, or send us the model number and we'll confirm compatibility.

Which TV and display brands does this mount work with?

Because it covers VESA patterns up to 600x400mm and up to 70 kg, it fits most 37 to 80 inch displays from major brands including Samsung, LG, Sony, Hisense, and commercial signage manufacturers. Always check your display's VESA pattern and weight in its manual, or send us the model number to confirm.

How much does this mount tilt?

It tilts from +3 to -20 degrees, letting you angle the display for the best viewing position beneath the ceiling. The detachable VESA plate also swivels for flexible positioning during installation.

How much height adjustment does the pole offer?

The double-pole design telescopes from 695mm to 1565mm (27.4 to 61.6 inches), giving installers a wide window to match a range of real ceiling heights from a single mount.

Does mounts.ae offer installation services?

Yes. Mounts.ae offers professional installation across the UAE as an add-on to your order. Simply select the installation option when you submit the Request a Quote form, or mention it when you message us on WhatsApp, and we'll include it in your quote alongside the mount itself. See our installation services page for full details on residential and bulk installs.

How do I order this for a bulk or project installation?

Use the Request a Quote button on this page, or message us on WhatsApp with your quantity and project details. We supply system integrators and businesses on a project basis across the UAE and GCC, and we'll follow up with next steps for your requirement.

Where can I buy VSYS ceiling mounts?

VSYS ceiling mounts are available through mounts.ae, based in the UAE and serving system integrators and businesses across the UAE and GCC. Use the Request a Quote button on this page, or message mounts.ae directly on WhatsApp, to get started with your order or enquiry.
